The MAX 10 Plus from Terasic is a full featured embedded evaluation kit based upon the MAX10 family of Intel FPGAs. It offers a comprehensive design environment with everything embedded developers need to create a processing based system.

The MAX 10 Plus delivers an integrated platform that includes hardware, design tools, intellectual property and reference designs for developing a wide range of audio, video and many other exciting applications.

The fully integrated kit allows developers to rapidly customize their processor and IP to suit their specific needs, rather than constraining their software around the fixed feature set of the processor. The all-in-one embedded solution, the MAX 10 Plus, making the best use of the parallel nature of FPGAs.

▲ SDRAM Memory Solution	▲ Capacitive Component Solution	▲ Power Solution

▶ Specifications

FPGA Device

• MAX 10 10M50DAF484C6G Device
• Integrated dual ADCs, each ADC supports 1 dedicated analog input and 8 dual function pins
• 50K programmable logic elements
• 1,638 Kbit M9K Memory
• 5,888 Kbits user flash memory
• 144 18 × 18 Multiplier
• 4 PLLs
• Programming and Configuration
• On-board USB Blaster
• Optional JTAG direct via 10-pin header
• One slide switch for dual boot image selection


Memory Devices

• 64Mx16 1 Gb DDR3 SDRAM
• 128Mx8 1 Gb DDR3 SDRAM
• 512Mb quad serial peripheral interface (quad SPI) flash memory
• Micro SD card socket
• Communication and Expansion
• Gigabit Ethernet PHY with RJ45 connector
• UART to USB
• PS/2 mouse/keyboard connector
• 2x6 TMD Expansion Header


Audio

• 24-bit CD-quality audio CODEC with mic-in, line-in, line-out jacks

Video Input

• HDMI video input

Analog

• Two MAX 10 FPGA ADC SMA inputs
• Potentiometer input to ADC
• On-Board MIC input to ADC
• 2x10 Header for MAX 10 FPGA ADC inputs
• One DAC output

Sensors

• Humidity and temperature sensor
• Light sensor
• Accelerometer
• Power monitor

Clocking for users

• One 10 MHz single-ended, external oscillator clock source
• Three 50 MHz single-ended, external oscillator clock source

Switches, Buttons and LEDs

• Five push-buttons
• Ten slide switches
• Ten red user LEDs
• Two 7-segment displays

Power

• 5V/3A DC input　

▶ Layout

• PCB Size：233.35*160 mm

▶ Resouces

Documents

Title	Version	Size(KB)	Date Added	Download
MAX 10 Plus User Manual	1.0	6647	2019-06-04
