Product information "PCIe FMC Carrier with Xilinx Virtex-7 FPGA, 8 Lane PCIe GEN2, SO-DIMM SDRAM"

This article is the replacement for the TEC0330-04.

The Trenz Electronic TEC0330 is a PCI Express form factor card (PCIe 2.0 or higher) integrating the Xilinx Virtex-7 XC7VX330T FPGA chip. This high-end FPGA card is designed for maximum system performance and intended for use in applications with high demands on system throughput. There is a SO-DIMM socket on the board for standard DDR3 SDRAM extension memory module.

The TEC0330 features HPC (High Pin Count) ANSI/VITA 57.1 compatible FMC interface connector for standard I/O Mezzanine modules. Other interface connectors found on-board include JTAG for accessing FPGA and on-board System Controller CPLD, and also connector with 5 high-speed I/O differential signaling pairs.

The TEC0330 FPGA board is intended to be used as add-on card in a PCIe 2.0 or higher capable host systems, it can not be used as a stand-alone device.

Key Features

  • Xilinx Virtex-7 FPGA module XC7VX330T-2FFG1157C (commercial temperature range)
  • PCI Express 2.0 x8 card with maximum throughput of 4 GB/s
  • FMC High Pin Count (HPC) connector
  • 8 FPGA MGT lanes available on PCIe interface
  • DDR3 SO-DIMM SDRAM socket
  • 256-MBit (32-MByte) Quad SPI Flash memory (for configuration and operation) accessible through:
    • FPGA
    • JTAG port (SPI indirect, bus width x4)
  • External clock input via SMA coaxial connector
  • 28 GTH transceivers, each with up to 13.1 Gbit/s data transmission rate
  • FPGA configuration through:
    • JTAG connector
    • SPI Flash memory
  • Programmable quad clock generator
  • TI LMK04828B ultra low-noise JESD204B compliant clock jitter cleaner
  • On-board high-efficiency DC-DC converters
  • Up to 202 FPGA I/O pins available on FMC connector (up to 101 LVDS pairs possible)
  • System management and power sequencing
  • AES bit-stream encryption
  • eFUSE bit-stream encryption

Other assembly options for cost or performance optimization plus high volume prices available on request.

Development Support

Latest documentation, design support files and reference designs with source files are available for download free of charge.

Scope of Delivery

  • 1 x TEC0330-05 Trenz Electronic PCIe FMC Carrier with Xilinx Virtex-7 330T FPGA

Additional Information

All modules produced by Trenz Electronic are developed and manufactured in Germany.
