Gigabit Ethernet interface, HDMI output interface, USB2.0 communication interface, Uart communication interface, SD card interface, RTC circuit meet the requirements of video image processing and industrial control
Supporting Verilog HDL Demos and Docuemnts,All Doucments Saved in Dropbox, after buy the board, email to get it.
01. Pango Design Suite 2021.1-sp7 Installation
02. LED water lamp experiment and simulation
03. Key detection experiment
04. PLL phase-locked loop output test
05. Serial port Transmitting and Receiving experiment
06. Key debounce experiment
07. I2C Interface EEPROM Experiment
08. SD Card Read and Write Experiment
09. HDMI Programming Output Experiment
10. 4.3 inch screen color bar output
11. 7-inch screen color bar output
12. SDRAM read and write data testing
13. AN831 Recording and Playback
14. SD Card Music Player Experiment
15. Character HDMI display
16. Character 4.3 inch screen display
17. Character 7-inch screen display
18. SD card image HDMI display
19. SD card image 4.3 inch LCD display
20. SD card image 7-inch LCD display
21. AN5640 monocular camera captures HDMI display
22. AN5640 camera captures a 4.3 inch screen display
23. AN5640 camera captures 7-inch screen display
24. AN5642 binocular camera captures HDMI display
25. Camera edge detection HDMI display routine
26. Camera edge detection 4.3 inch screen display routine
27. Camera edge detection 7-inch screen display routine
28. AD9238 waveform display routine
29. AD7606 waveform display routine
30. ADDA Test Routine
31. AD9767 Dual Channel Sine Wave Generation Routine
32. AD9767 Dual Channel Triangular Wave Generation Routine
33. RTC Clock Experiment
34. Gigabit Ethernet Transmission Experiment
35. AD9238 Ethernet Transmission Routine
36. AD7606 Ethernet Transmission Routine
37. AD9280 Ethernet Transmission Routine
38. AN5640 Gigabit Ethernet for video transmission
39. AN5642 Gigabit Ethernet for video transmission
40. USB bidirectional speed measurement routine
AN108 Collection Packag
AN9767 Collection Package
AN706 Collection Package
AN9238 Collection Package
Single camera video package
Luxury Package
FPGA Board
●
●
●
●
●
●
USB Downloader
●
●
●
●
●
●
AN108
●
●
AN9767
●
●
AN706
●
●
AN9238
●
●
AN5640
●
●
4.3-Inch LCD
●
●
Supporting Modules in the Package, Click to Learn More
Learn More about the Core Board, Click to View>>
FPGA Chip
PGL12G-6CFBG256
LUT4
12480
Flip-flops
15600
18Kb DRM
30
APM
20
PLL
4
ADC
1
user IO
106
Active crystal oscillator
50Mhz active crystal oscillator
SDRAM
1 Winbond SDRAM chip, 256Mbit
QSPI Flash
1 64Mbit QSPI FLASH chip
LED灯
2 LED lights
Expansion
2 high-speed expansion ports
power supply
+5V
Speed level
-6
Temperature rating
Commercial
Gigabit Ethernet
10 / 100M / 1000M Ethernet RJ-45 Interfaces for Ethernet Data Exchange
HDMI Output
One HDMI video output interface
USB
Used for USB 2.0 High Speed Communication with PC
SD Card Slot
1 Micro SD Card Slot, Support SPI Mode
Uart
Used for Serial Communication with PC or External Devices
EEPROM
EEPROM 24LC04 with IIC Interface
Real Time Clock
RTC with a Battery Holder, The Battery Model is CR1220
40-Pin Expansion Ports
one 40 pin 2.54mm spacing expansion port for various external modules (binocular camera, TFT LCD screen, high-speed AD module, etc.). The expansion port includes 1 x 5V power supply, 2 x 3.3V power supplies, 3 ground power supplies, and 34 IO ports.
JTAG
A standard 10 pin 2.54mm spacing JTAG interface for downloading FPGA programs or solidifying programs to FLASH
CAMERA
An 18 pin CMOS camera interface for connecting to the OV5640 camera module, which can achieve video capture function
key
4 Keys
LED
5 LEDs(1 in the Core Board, 4 in the Carrier Board)
power supply
+5V DC ,Max. Current 2A
FPGA Board
1
downloader
1 Set
Mini USB Cable
1
5V Power Adapter
1
Transparent Protection Board
1
Size Dimension
130mm x 90mm
Number of Layers
8-Layer Core Board PCB, 4-Layer Carrier Board PCB
Industrial Ethernet, high-speed video processing transmission, optical fiber communication and high-speed data transmission and exchange
The binocular camera module AN5642 performs video capture, and the HDMI interface is displayed on the monitor to achieve binocular synchronous display
Display diagram of AN9767 / AN706 module on computer
*The Signal Source Output Signal is Connected to the AN9767 Module, and the Waveform Signal is Displayed through the Oscilloscope
*The Signal Source Output Signal is Connected to the AN706 Module, Run the System to Draw the Waveform Data, and is Displayed to the Monitor through the HDMI Interface of the FPGA Development Board
